Fortpro Air Spring Replaces 8852, 1R12-568 | F245596
Fortpro Air Spring F245596 is a high quality, exceptional performance automotive suspension component. Engineered with robust materials and enhanced features, it offers strength, durability and a multi-model compatible fit. With rigorous leak testing and proper technical specifications, this air spring provides reliability and improves vehicle suspension.
Specifications:
- Brand: Fortpro
- Part Type: Air Spring / Air Spring Bag / Suspension Air Spring
- Vehicle Type: Semi-Trucks, Heavy-Duty Trucks
- Part OEM: 8852, W013588852, W01-358-8852
- Position: Primary Truck & Trailer Axle
- Air Spring Style: 1T Reversible Sleeve
- Piston Type: Composite
- Bead Plate Diameter Bottom: 10.25"
- Bead Plate Diameter Top: 9.00"
- Collapsed Height: 6.70"
- Max. Height: 23.50"
- Part Diameter: 10.12"
- Piston Height: 5.69"
- Stud Configuration-Bottom: 1
- Stud Configuration - Top: 3
- Weight:: 13.19 lbs
- Application: Peterbilt 03-07887 (Low Air Leaf)
- VMRS: 016-008-000
CrossReference:
- Automann: 566CT64339, AB1DK23L8852
- Contitech: 91019P472
- Dayton Parts Batco: 1R121081, 1R12568, 3528852
- Firestone: 8852, W013588852, W01-358-8852
- Goodyear: 1R12568, 1R12568
- Meritor: FS8852, MAF8852
